Brief Introduction of NFA WHP3 Project---Deping’s internal line up clamp with laser & camera kit
Project Full Name： EPIC for Topside, pipeline & Modification for new wellhead platform (WHP)-3 near NFA complex
In the beginning for Year 2017, Deping kicked off the research and development of laser and camera system for inspection, after the product was finalized, it was used in the pipe for test, the engineer from the Third party BV was invited to conduct test in our factory by comparing test datas from CMM coordinate measuring machine and laser and camera system, BV engineer concluded the accuracy level of laser and camera system is 0.2mm, the result was satisfactory.
Advantages of using internal pneumatic line up clamp manufactured by DEPING TECHNOLOGY
The series of internal line up clamp of LOYANG DEPING TECHNOLOGY CO., LTD is specially developed for cases when the welding technology foresees the formation of the root of the seam using a copper shoes.
Automatic welding systems enable various degrees of automation of the girth welding process. The method combines well with others, such as manual and semi–automatic welding.
Prior automatic welding process, the shape of pipe end need to be beveled like U shape, V shape, X shape, etc, it will request the special equipment names Pipe facing machine, normally pipe facing machine will bevel pipe material is Carbon Steel pipe, X70~X90, different wall thickness, in order to suitable for various client request and pipe material, we still design and manufacture the special pipe facing machine for CRA pipe, the pictures are as below:
Classification & Application of Internal line up clamp
Internal line up clamp is mainly used to align two pipes in long distance of oil and gas pipeline construction projects.With the development of Internal line up clamp, urban water and heat pipeline construction also begin to choose the Internal line up clamp finish the pipe aligning.
Internal line up clamp not only ensure the efficiency but also improve the quality of the pipeline construction.
Few days ago, in the workshop of Luoyang Deping Technology Co.,Ltd ,General Manager Mr.Wang despite the greasy dirt on the pipe, carefully check the newly developed automatic welding systems’ weld joint quality.
